Built-in Screen : YES
Loop-Cycle Recording Feature : YES
NightShot Function : YES
Rear Camera : YES
Display : IPS
Touch Screen : YES
Memory Card Required Reding Speed : Class 10
View angle : 170
Camera Resolution : 1920x1080
Video Code : H.264
Special Features : G-Sensor,Parking Monitor
Max External Memory : 128G
Number Of Lenses : 4
Imaging Sensor : Sony IMX323
Interface : USB2.0,Micro SD/TF
Assembly Mode : Portable Recorder
Chipset Manufacturer : JIELI
Frames Per Second : 10
Origin : Mainland China
Certification : CE
Item Type : Car DVR
OEM NO. : 360° Panoramic Dashboard Car DVR
360° Panoramic Dashboard Car DVR 12-Inch Touch Screen 4 Channel FHD 1080P IPS Video Recorder 4 Split Screen Display Dash Cam
Featutes:
【4 CHs record , 360°panoramic view】with 4 cameras recording at the same time, that mean tall the videos from 4 cameras be saved in the SD card.The 4 image will be displayed in the 12 inch display as 1:1:1:1.
【No-light night vision】T66 is one non-android mirror car DVR, it has the super night vision,even in the full darkness,to ensure you get the very clear video and image . you no need worry there is not road lamp in the remote village.
【Auto reverse parking view】When the car in Reverse Gear, this car DVR will automatically switch to the back-up camera image view with parking line.
【G-sensor】It will defect the collision and save the video and image into SD card, so that they will not be covered by the loop recording.
【Loop recording】When the SD card is full, T66 will cover the previous video files to continue recording. It could support the max 128G SD card with class 10 or above.
1. It fit the wide voltage 9-36V, so suitable for bus, truck and car installation.
2. It get power from the car battery, and the ACC wire connect to the key ignition.
3. It supports four segments, single screen and other segmentation display for the video or image.
4. The display resolution is 1920*720P.
5. there is the ACC trigger wires for the reverse parking, left turn and right turn. when in the auto reverse gear, it will switch to the image from back cam with parking line for reference. when you are in left or right turn, the image from left or right side camera will be display on the screen for your check.
6. It support the max 128G card for the video recording.
7. Video format is MOV and its is H.264 code, the video files could be played on PC.
8.4CH universal aviation connectors, cameras are 5V power supply, stable and short-circuit protected.
9. It will not jam or crash after long time work, because it is equipped with the strong heat dissipation.
10. It supports mixed signal input.it could be used after set and save.
Description:
Screen: 12 inch press screen
Operation System: UC
Power Range: 9V-36V
Video Format: H.264, MOV
Video resolution: AHD 1280x720P
Video Standard: ISO14496-10
Audio Input: Support
Video Input: CH1-CH4, support AHD
Video Storage: Support max 128G card with class 10 or above
Operation Temperature: -40℃~80℃
Display Mode: Support 4 segment, 2 segment or full screen display for the video
Colour: black
Material: ABS
Package Contents:
1 x T66 car camera
1 x front camera
1 x rear camera
1 x Left side camera
1 x Right side camera
1 x 8 meters cam cable
3 x 3.5 meters cam cable
1 x center console base
1 x english manual
Note：
Only the above package content, other products are not included.
Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
360 degree view angle
it support the 4 cams record at the same time, thus you could check the situation around your loved vehicle all the time.
NO light night vision
even in the full darkness, the video and image is very clearly.
4 split display on 12in screen
it is 12inch touch screen and support the 4 split display on the screen.
Two install way
you could install it with the center console base or special mount.
Reverse parking
when in auto gear, it will switch to the rear camera image with the parking line for your reference.
