PATLITE Network Monitoring Indicator Light Indicator Red Yellow Green (Large Light/3 Tiers) NHL-3FB2-RYG

Network monitoring indicator. A product that can be easily controlled via LAN connection and can also monitor itself, helping to visualize IT (fault) information. Equipped with a wide range of control commands and a variety of monitoring functions. Improved compatibility with various monitoring devices and systems. Rated voltage DC24V (AC adapter used: input AC100~240V (50/60Hz)) Rated power consumption Main unit Maximum volume: 4.0W Indicator light: 3.0W Installation location and direction Indoors, forward direction Protection class IP20 Mass (tolerance ±10%) 780g (excluding AC adapter) Main unit size W69xD126xH324mm Indicator light outer diameter 60mm Number of indicators: 3 Indicator color: Clear lens type | Red | Yellow | Green | Buzzer: HIGH: 80dB or more, LOW: 70dB or less (at 25℃) 1m from the product in front, A-characteristic Communication specifications (physical layer to application layer) Physical layer: Ethernet (IEEE802.3 compliant) 10BASE-T/100BASE-TX (auto-negotiation, full duplex/half duplex) Data link layer: CSMA/CD Network layer: IP, ICMP, ARP Transport layer: TCP, UDP Application layer: HTTP, SMTP, SNMP, RSH, NTP, POP, DNS, SOCKET, DHCP, SLMP Compliance standards RoHS Directive (EN 50581) EMC Directive (EN55032, EN55024) FCC Part 15 Subpart B CLASS B, ICES-003 Class B UL 1638, UL 464, CSA C22.2 No.205 PSE specific electrical equipment (only the included AC adapter, the main unit is not PSE-compliant)
