Mini Microcomputer Thermostat Regulator DC 12V 10A Digital Temperature Controller -50-110C

Mini Microcomputer Thermostat Regulator DC 12V 10A Digital Adjustable Temperature Controller -50-110C

Feature Color: Black Temperature measurement range: -50 110degC Resolution Ratio: 0.1degC(-9.9-99.9); 1degC(other temperature range) Measurement accuracy: plusmn0.1degC Control accuracy: 0.1degC Return difference accuracy: 0.1degC Refresh rate: 0.5S High-temperature protection: 0-110degC Input voltage: DC 12V Measuring inputs: NTC(10K0.5%)Waterproof type sensor Output: 1 way 10A relay Environmental requirements: -10-60degC , humidity 20% -85%RH Size: 48mm(L)*29mm(W)*32mm(Depth) Hole size: 46*26.5mm Power consumption: Static current: le35MA,attract current: le65MA Power supply: 12V200MA The upper number displays actual temperature, and the lower displays setting temperature. When the actual temperature is higher than the setting temperature, the temperature controller brackovers, and conversely, it disconnects. Please act strictly according to the line connection and the positive and negative pole on user manual!

Package Content 1x 12V Temperature Controller 1x Temperature sensor probe 1 x English Manual
