Applicable Models & Years
For Seat
For Altea ab 05/2004
For Toledo ab 12/2004
For Leon ab 09/2005
For Altea XL ab 04/2007Alhambra ab 2010
For VW
For VW/SAGITAR/JATTA/JETTA
For VW/MAGOTAN/MAGOTAN V6
For VW/PASSAT B6
For VW/PASSAT V6
For VW/MAGOTAN VARIANT
For VW/PASSAT B7
For VW/PASSAT NMS
For VW/PASSAT Variant
For VW/PASSAT CC
For VW/PASSAT TSI
For VW/TOURAN
For VW/GOLF V
For VW/GOLF VI
For VW/GOLF VARIANT
For VW/TIGUAN / TIGUAN GP
For VW/SHARAN
For VW/CADDY
For VW/POLO
For VW/EOS
For VW/SCIROCCO
For A part of VW/T5/TRANSPORTER
For VW/R36 VARIANT
For VW/BEETLE
For VW/MULTZVAN
For VW/GOLF CROSS
For VW/GOLF BLUE MOTION
For VW/SPORTLINE
For VW/BORA
For VW/AMAROK
For Skoda
For Fabia Limousine ab 02/2007 bis 2012
For Fabia Combi ab 04/2007 bis 2012
For Praktic ab 04/2007 bis 2012
For Roomster ab 04/2006 bis 2012
For Octavia Combi 06/2004 bis Facelift
For Octavia Limousine ab 06/2004 bis Facelift
For Octavia II 2& III3
For Yeti ab 2009 bis 2012
For Superb/3 T ab 2008 bis 2012
Seven Options:
Option 1: 8GB (RAM) + 128GB (ROM)----suport 4G-LTE & WIFI with AI Assistant ,AHD Rear Camera,External Mic, Cooling Fan.
Option 2: 6GB (RAM) + 128GB (ROM)----suport 4G-LTE & WIFI with AI Assistant ,AHD Rear Camera,External Mic, Cooling Fan.
Option 3: 4GB (RAM) + 64GB (ROM)----suport 4G-LTE & WIFI with AI Assistant ,AHD Rear Camera,External Mic, Cooling Fan.
Option 4: 4GB (RAM) + 32GB (ROM)----suport 4G-LTE & WIFI with AI Assistant ,AHD Rear Camera,External Mic, Cooling Fan.
Option 5: 3GB (RAM) + 32GB (ROM)----suport 4G-LTE & WIFI with AI Assistant ,AHD Rear Camera,External Mic, Cooling Fan.
Option 6: 4GB (RAM) + 32GB (ROM)----suport WIFI with AI Assistant ,AHD Rear Camera,External Mic, Cooling Fan.
Option 7: 3GB (RAM) + 32GB (ROM)----suport WIFI with AI Assistant ,AHD Rear Camera,External Mic, Cooling Fan.
Item Parameters:
General
- Power Supply: DC 12V (allowance range: 10.8-14.5V)
- Max. Current: 10A
- Screen Size: 9 inch
System
- Operation System:Android 12
- CPU: Octa Core ,UIS 7862A 1.8Ghz*8 (for S1/S2/S3/S4 Version) / UIS 7862S 2.0Hhz*8 (for S5/S7/S8 Version)
- RAM: 3GB / 4GB / 6GB / 8GB
- ROM: 32GB / 64GB / 128GB
Display
- Touch Screen: Yes
- Resolution: 1080*720 QLED Screen
- Capacitive or Resistance Screen: Capacitive
- Built-in Clock and Calendar: Yes, show real time and can use network-provided time
- Main Menu Status Bar display: Can be changed to Music/Radio/BT-Stereo Player and Clock/Date/Week
- Change Apps-Icon Position: Yes
WiFi/4G LTE
- WiFi: Built-in WiFi Modem, support 802.11b/g/n
- 4G LTE module: Built-in (S1 /S2 Version not included,which only support the WIFI)
- 4G LTE sim card slot: Yes
- 4G LTE Antenna: YES
- You just need to insert the 4G LTE sim card before you can enjoy the 4G LTE serivce.
Internet
- Explorer: Opera, UCWeb, SkyFile, Dolphin and more explorer for your selection
- Online Entertainment: Online Video, TV, Movie, Music, Radio, Video Chat
- Online Navigation: Online Google Maps Navigating
- Online Games: Yes, online play or you can download it from google play store
- Online Communication: WeChat, Twitter, Facebook, Skype, Gmail, Whatsapp etc.
- Read and edit Office Software: Yes, support Word, Excel, Powerpoint, PDF, TXT
Audio
- Format: MP3/WMA/MP2/OGG/AAC/MA4/FLAC/APE/WAV etc. Could play via song list
- Record: MP3, WMA
- Other: LRC synchronized display; ID3 search; Search by files; Album Picture; User-defined audio effect
- Amp IC: YD7388
- SNR: Noise rations:=90dB
Video
- Format: Support AVI (H.264, DIVX, XVID), RM, RMVB, MKV (H.264, DIVX, XVID). WMA, MOV, MP4 (H.264, MPEG, DIVX, XVID). DAT (VCD format). VOB (DVD format). PMP, MPEG, MPG. FLV (H.263, H.264). ASF, TS, TP, 3GP, MPG etc. =30 formats, Playing internet video directly (while downloading)
- Play: Up to 1920*1080 Pixels, 30Mb. Fluent play without light spot
GPS
- Operation System: Android
- Support Maps: Android Map, IGO, Sygic, Kudos
- Voice Guidance: Yes
- Support 2D/3D Map Views: Yes
- Dual Zone: Yes, navigating while music playing
- Online Navi: Yes, support google maps online navigating
Bluetooth
- Hands Free: Yes
- A2DP (Bluetooth Stereo Music): Yes, can play stereo music through Bluetooth
- Bluetooth Music Control: Yes, play/pause/previous/next
- PB-Download: Yes, can download phonebook from mobile to this unit
- PB-Search: Yes, can use the first letter to search contact member in PB-Listings
- Calling Records: Yes, Dialed Call, Received Call, Missed Call
- Setup: Auto Answer, Auto connect, Device name
- Built-in Microphone: Yes, on the front panel
- Bluetooth Version: 5.0
Radio
- FM Tuning Range: 87.5-108MHz
- FM Increment: 0.05MHz(EU)/0.1MHz(US)
- FM Area: Europe/USA1/USA2/Japan/Russia
- RDS: On/Off
- It doesn't support XM radio, but you can access the same channels using the XM radio app.
1. Smart Car Infrtainment: AI Voice Control System Open safe Driving
2. Car Model: This unit will fit the following car model
3. User interface:
S Series(can set as 4 color type: Purple/ Dark blue / Black / Golden) included S8/ S7/ S6/ S5/ S4/ S3/ S2/ S1 version
4. Extreme Performance: A new generation of new CPU architecture, equipped with Two A75,six A55,super performance release ,easy to deal with daily needs.
The specific CPU model please refer to the products configuration table.
5. Support Carplay / Android auto: Phone / Music / Maps / Podcasts Make your journey easier and more fun.;support wireless carplay,wired android auto,wireless android auto(which needs to set its cell phone wifi hotspot's AP Band as 5 Ghz band).
6. Built-in DSP BU32107EFV: We use BU32107EFV and BD37534FV DSP IC in different configurations products.The specifit difference please refer to the first picture of product configurations table.
7. Professional radio chip: Receive more stable radio station ,less radio noise, higher performance during driving.
(We use 4745,TDA7708 and integrated radio IC in different configurations products, the specific different please refer to the products configuration table.)
8. Bluetooth 5.0 Dual Channel: Stable and long distance Bluetooth connection. Stable and long distance WIFI connection.
(On its main interface can show "Model phone battery display")
9. Built-in 4G Network: Please enter the SIM card before turn on the device. Include the 4G card slot, and the 4G antenna!(this Function for S3 / S4/ S5/ S6/ S7/ S8 version)
10. Audiovisual Feast
11. 1280*720 QLED Screen : Fine picture quality, true color, suiltable for more scenes, to meet your requirements
12. Button color changing function: Original Light color ,Red ,Yellow ,White ,Green ,Blue ,Cyan ,Purple.
13. AI Voice Car System Relax Driving( BE actived before ship out)
14. Weather Display (BE actived before ship out)
15. Multiple Desktop Window Function (For example: GPS ,OBDII , DVR , TPMS )
16. Navigation , Weather Display , Split Screen ,Bluetooth phone,Radio functions ,One key to enter the secondary page, Customizable application add,delete,move.
17. can Support Torque Pro ( OBD2 & Car ) / DAB+ Box / TPMS Function / Supports AV-OUT / HD 1080P ADAS DVR Camera / and etc, but needs the buyer to order the adapter separately if needs.
18. GPS Navigation: Supports Online and Off line Google map, Navitel, Waze, Herewego
To avoid congestion choose lanes recently , the way of voice complement sensory information.
19. Optical and coaxial digital audio output : This function is only supported by S5/S6/S7/S8 series
20. Split Screen : You can use 2 apps at the same time (such as: Navigation + Music , ADAS Camera + Music ,etc.)
21. PIP(Picture in Picture): the ability to watch video in small window on top of the screen, you car adjust the size.
22. Rear View System(please set its rear camera type on its system before installing if your rear camera is not as AHD type): A car video system that supports a backup camera displays troublesome blind spots on a monitor , allowing a driver to see hazard such as pets ,children playing ,or mailboxes ,as they backup.
