12" IPS Touch Screen 4K Front Camera Dash Cam - Supports Wireless CarPlay/Android Auto with G-Sensor & FM Transmitter
1. Product Features
12" IPS Touch Screen: No blind spots, offers clear visual experience for operation and video viewing.
Rapid Cold Boot: Starts up in only 3 seconds, saves waiting time for immediate use after ignition.
4K 2600P Front Camera: Boasts up to 8 million pixels and true 3840×2160P UHD resolution, enabling clearer and farther viewing of road details.
Wireless CarPlay & Android Auto: Supports screen projection; 4K recording remains available during projection, no conflict between navigation and video capture.
Siri Voice Control: Exclusive to CarPlay, allows hands-free operation (e.g., making calls, sending messages) for safer driving.
FM Transmitter: Pair once for automatic subsequent connections; plays audio via the original car audio system to enjoy original sound quality.
Aluminum Super Capacitors: 3.8V 30F specification, superior to lithium batteries in temperature resistance and safety, ensuring long-term stable performance.
5GHz High-Speed WiFi: Transmits data faster and more stably, with video transfer speed increased by approximately 5 times compared to conventional WiFi.
H.265 Video Encoding: Upgraded coding scheme saves over 30% storage space compared to H.264, allowing more video recordings with the same memory capacity.
Loop Recording: Operates stably, records long-term without missing seconds or crashing, and stores files cyclically to avoid memory full issues.
G-Sensor Function: 3-axis (DA380) sensor detects sudden acceleration, braking, and collisions, automatically capturing and protecting accident-related footage; critical files won’t be overwritten by loop recording.
2. Product Specifications
Category Details
Key Components
Main Chip Rackchip RV1126 (4×CA7@1.5GHz, RISC-V MCU@200MHz)
Display MIPI 11.26 inches, Resolution: 1920×440
TP (Touch Panel) Supports 12-inch capacitive screen
DDR (ROM) 32-bit LPDDR3, Max 512MB
Flash Memory SPI NOR 32MB
WiFi & BT FG6222BSRC/FG6221BSRC (2.4G/5G WiFi + BT4.2)
FM Transmitter QN8027
Super Capacitors 3.8V 30F
Loudspeaker Built-in (8ohm/1.5W), Power amplifier: NS4890
Microphone Built-in (-35dB ±2dB)
Front Camera Sensor IMX415
Gravity Sensor 3-Axis (DA380)
Ports
- TF card slot (SD Socket), supports up to 128GB expansion
- Type-C 16pin right bend 90° (power supply: buck line/car charger DC5V/2.5A)
- 1×GPS 3.5mm Jack (optional accessory, software functions to be developed)
- 1×AHD Rear Camera Jack (2.5mm 4-segment), compatible with auto-reverse
Physical Buttons 1×Power Key, 1×Reset Key, 1×Download Key (behind 3.5mm jack, for easy upgrade)
Software
OS Linux 4.9
UI Built-in UI
Projection Screen Supports Android Auto / CarPlay
ADAS Not supported
Languages Simplified Chinese, Traditional Chinese, English, Japanese, Russian, French, etc.
Encoding Format H.265 / H.264 Video Code
Monitoring Parking Monitoring (vibration wake-up, 20-second time-lapse video)
